Simplex Demand Control Panel - 208/230V Single-Phase
SKU: 50A002-NF
Price: $545.99
SPI Model SSC2B
- 208/230V Single-Phase Simplex Demand Control Panel
- 4x Rated Durable, Weather-Resistant Enclosure with Mounting Feet and Stainless Steel Latch
- Main Circuit Breaker
- Definite Purpose Motor Rated Contactor
- Easy to Access Finger Safe Terminal Block
- Usable with 208 or 230 VAC
- Secondary Fuse Protection for Control Circuit
- Pump Hand-Off-Auto Switch with Pump Running Light
- Full Alarm Circuit (Visual and Audible Alarms)
- Alarm Test and Silence Switch
- Color Coded Internal Wiring
- Connection Diagram and Schematic
- 3 Float System (Off, On and High Water)
- Built and Labeled to UL 508A Standard
- FLA Range 0-20
Spec Sheet
Connection Diagram
Manufacturer: SPI
Weight: 13 lb
***Featured Item***
Delivery: Ships in 4-10 Business Days
- Fiberglass Enclosure
- IEC Motor Contactor
- Flasher
- Dead Front Inner Door
- Auxiliary Alarm Contacts
- Elapsed Time Meter
- Event or Cycle Counter
- Mercury or Mechanical Float Switches for the Pumps and High Water Alarm Circuits
